XB50 CASAMBI 6-in-1 CV Controller
.jpg)
1 / 4 XB50 LED controller is designed to drive single color to RGB+CCT constant voltage LED products in voltage range of DC 8-50V . With powerful functions of Casambi platform, it also has advanced user parameters to fine tune the application. It has full protection function to ensure the safety, and with push cable connectors, the installation will be simple and reliable.
| CASAMBI CV LED controller | |
| Model | XB50 |
| Function | 6-in-1 CV controller (Single color, CCT, RGB, RGBW, RGB+CCT and 5-ch dimmer) |
| Electrical Specification | |
| Working Voltage | DC 8-50V |
| Rated Output Current | CV mode, each channel 8A, total max 24A |
| Smartphone Connection | by CASAMBI app, based on BLE |
| RF Band | 2.4GHz, 433MHz(with optional RF remote controller) |
| Wireless Transmit Power | <7dBm |
| App Support | CASAMBI App on iOS and Android platform |
| Output PWM Frequency | 498Hz-20.4KHz configurable from app (10 levels) |
| Protection Function | Wrong wiring / Overload / Short circuit / Overheat |
| Working Temperature | -30~60℃ |
| Functions | |
| Model profile | Single color, CCT, RGB, RGBW, RGB+CCT, 5-ch Dimmer; configurable from app |
| Smartphone Control | dimming, color setting, group features, via Casambi app |
| RF Remote Control | RM05 or compatible 433MHz RF remote controller |
| Press Key Control | On/off, dimming |
| Gradient speed | Adjustable from app |
| Power & LED Connector | |
| Power Connector | Wago804 push connector |
| LED Connector | Wago804 push connector |
| Dimension & Weight | |
| Dimension | 134x39x24mm |
| Net Weight | 63g |
Specifications are for reference; please refer to the user manual for details.
