T710 RF Remote Digital SPI Controller
1 / 3 T710 SPI LED controller is designed to drive various digital chasing LED strip or spot lights with decode IC, It works with power voltage of DC12V-24V. It contains a main unit and a RF wireless remote controller. User can setup dynamic effect or static color from the remote controller. With the RF wireless remote control, user can setup patterns freely and save the favourite on the remote shortcut keys.
| T710 RF Remote Digital LED Strip Controller | |||
| Model | T710 | ||
| Model Suffix | Model Suffix: S-shrink tubed lead wire, H-ABS housing, D-DC barrel connector, M-With Magnet remote holder. | ||
| Electrical Specification | |||
| Working Voltage | DC 12-24V | ||
| Remote Control | RF wireless slim remote controller | ||
| Remote Control Frequency | 433.92MHz | ||
| Remote Control Battery | CR2032 3V cell battery | ||
| Remote Transmit Power | <10dBm | ||
| Remote Distance | >15 meters in open area | ||
| Remote Controller Paring | Receiver and remote controller 1 to 1 paired | ||
| Driving Range | 200 Pixels | ||
| Data Format | Single data wire SPI mode | ||
| Working Temperature | -20~55℃ | ||
| Functions | |||
| Dynamic Effects | 594 effectcs, with adjustable direction, unit length and running speed | ||
| Static Color | 29 static colors, with adjusable brightness | ||
| Power & LED Connector | |||
| Power Connector | 5521 DC jack | ||
| Data Connector | 3-Pin SM type male connector | ||
| Dimension & Weight | |||
| Dimension | Main unit: 51x15x7mm; Remote Controller: 86.5x36x7.5mm | ||
| Net Weight | 25g | ||
Specifications are for reference; please refer to the user manual for details.
