NT12 Tuya Series Single color Controller
.jpg)
1 / 4 NT12 LED controller is designed to drive constant voltage single color LED products in voltage range of DC12-24V. It can be controlled by smart phone with Tuya smart app connection or by the stand alone RF remote controller. User can setup LED brightness, scene and dynamic effects with the rich function on smart phone Tuya app or the easy operation remote controller.
| NT series Tuya+Remote CV LED controller | |||||
| Model | NT12 | NT20 | NT30 | NT40 | NT50 |
| Model Suffix | W: Tuya Wifi; Z: Tuya Zigbee; B: Tuya Bluetooth | ||||
| Function | Single Color CV controller with RF remote controller | CCT CV controller with RF remote controller | RGB CV controller with RF remote controller | RGBW CV controller with RF remote controller | RGB+CCT CV controller with RF remote controller |
| Electrical Specification | |||||
| Working Voltage | DC 12-24V | ||||
| Rated Output Current | 10A | 2x5A | 3x4A | 5x2.5A | |
| Smartphone Connection | Tuya Wifi, Tuya Zigbee or Tuya Bluetooth | ||||
| Remote controller connection | 433MHz RF | ||||
| RF remote transmit power | <7dBm | ||||
| RF remote control distance | >10 meters at open area | ||||
| PWM output grade | 4000 levels | ||||
| PWM Frequency | 1KHz | ||||
| Protection Function | Wrong wiring / Overload / Short circuit / Overheat | ||||
| Working Temperature | -20~55℃ | ||||
| Functions | |||||
| RF remote control | Yes, with optional magnet wall holder | ||||
| Dynamic Mode | Yes | Yes | N/A | Yes | |
| Gradient Speed | Adjustable on app | ||||
| Power on Status | Adjustable on app | ||||
| Power & LED Connector | |||||
| Power Connector | Slot screw block terminal, max 12AWG cable | ||||
| LED Connector | Slot screw terminal, max 17AWG each slot (max 12AWG for NT12) | ||||
| Dimension & Weight | |||||
| Dimension | Main unit: 87x24x15mm, Remote: 86.5x36x7.5mm(122x35x9mm for NT12) | ||||
Specifications are for reference; please refer to the user manual for details.
