BR02 Umi BLE Handheld Remote
1 / 5 BR02 hand remote with simplified operation & minimalist design is designed to control Umi smart controllers and led drivers which has robust Umi wireless protocol based. This series has ultra low power and long life cell battery.
| Umi Handheld Common Remote Controller | |||
| Model | BR02-C | ||
| Function | On/off, dimming and color tuning. Work with all Umi receivers. | ||
| Electrical Specification | |||
| Working Voltage | DC3V, CR2032 cell battery | ||
| Wireless Connection | Umi protocol based on SIG Bluetooth mesh | ||
| RF Band | 2.4GHz ISM band | ||
| Wireless Transmit Power | <7dBm | ||
| Wireless Distance | >20 meters at open area | ||
| Standby Current | <1uA current | ||
| Working Temperature | -20~55℃ | ||
| Functions | |||
| Operation Mode | Click press / hold press / combo key | ||
| User Interaction | Variable brightness indicator | ||
| Installation | Optional magnet wall holder | ||
| Dimension & Weight | |||
| Dimension | 122x35x9mm | ||
| Net Weight | 25g | ||
Specifications are for reference; please refer to the user manual for details.
