BW05 Scene Touch Wall Panel
1 / 4 BW05 Scene touch wall panel with round tempered glass finish is designed to control single color to RGB+CCT Umi controllers and led drivers which has robust self-expandable Umi mesh wireless protocol. This series has AC power and cell battery power option and support favourites setting or group function.
| Umi Scene Function Touch Wall Panel | ||
| Model | BW05-A | BW05-B |
| Function | Switch to four scenes and turn off. AC powered. | Switch to four scenes and turn off. Cell battery powered. |
| Electrical Specification | ||
| Working Voltage | A version: AC 90-265V; B version: CR2032 cell battery | |
| Wireless Connection | Umi protocol based on SIG Bluetooth mesh | |
| Wireless Transmit Power | <7dBm | |
| Wireless Distance | >20 meters at open area | |
| Standby Power Consumption | A version: <0.5Watt; B version: <10uA current | |
| Working Temperature | -20~55℃ | |
| Material & Finish | Rounded tempered glass panel, PC housing | |
| Functions | ||
| Operation Mode | Touch sensing | |
| User Interaction | Indicator | |
| Installation | Screw installation with 86x86mm standard wire box or flat sticking for battery version | |
| Power & LED Connector | ||
| Power Connector | A version: Wago250 standard push connector; B version: N/A | |
| Dimension & Weight | ||
| Dimension | A version: 86x86x39mm; B version: 86x86x10mm | |
| Net Weight | A version: 128g; B version: 115g | |
Specifications are for reference; please refer to the user manual for details.
